Garrett GT2554R (170-270 HP)

Product image 1
Product image 2
Product image 3

Garrett GT2554R (170-270 HP)

Garrett GT2554R (170-270 HP)

Horsepower:
170 - 270
Displacement:
1.4L - 2.2L
Turbo Reference Data Compressor Turbine
Turbo PN CHRA Inducer Exducer  Trim A/R Inducer Exducer Trim A/R
836023-5001S 835995-0001 42mm 54mm 60 0.80 53mm 42mm 62 0.64



Features:

  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Sold as a complete turbo (includes turbine kit & actuator).
  • Smallest ball bearing configuration available.
  • Water cooled CHRA.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
$1,095.55
Garrett GT2554R (170-270 HP)—
$1,095.55

Product Information

Shipping & Returns

Description

Horsepower:
170 - 270
Displacement:
1.4L - 2.2L
Turbo Reference Data Compressor Turbine
Turbo PN CHRA Inducer Exducer  Trim A/R Inducer Exducer Trim A/R
836023-5001S 835995-0001 42mm 54mm 60 0.80 53mm 42mm 62 0.64



Features:

  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Sold as a complete turbo (includes turbine kit & actuator).
  • Smallest ball bearing configuration available.
  • Water cooled CHRA.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
