Garrett GT3582R (400-675 HP)

Product image 1
Product image 2
Product image 3
Product image 4

Garrett GT3582R (400-675 HP)

Garrett GT3582R (400-675 HP)

Horsepower:
400 - 675
Displacement:
2.0L - 4.5L
Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836033-5002S 836005-0003 61mm 82mm 56 0.70 68mm 62mm 84
Features:
  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Non wastegated turbine housings available.
  • Ball bearing configuration with water cooled CHRA.
  • V-band turbine housing options.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
Select Turbine Housing Option (A/R, Inlet, Outlet)
From $699.65

Original: $1,999.00

-65%
Garrett GT3582R (400-675 HP)—

$1,999.00

$699.65

Product Information

Shipping & Returns

Description

Horsepower:
400 - 675
Displacement:
2.0L - 4.5L
Super Core Reference Data Compressor Turbine
Super Core PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836033-5002S 836005-0003 61mm 82mm 56 0.70 68mm 62mm 84
Features:
  • Original GT series aerodynamics.
  • Internally wastegated turbine housing.
  • Non wastegated turbine housings available.
  • Ball bearing configuration with water cooled CHRA.
  • V-band turbine housing options.
Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
